EA-GA (Fruit and Vegetable)
- Capacity
- 3.28–62.23 kW
- Models
- 26
- Fans
- ⌀350–⌀630 mm
- Max. pressure
- 10 bar
Brine coolers
6 lines. Filter by parameters or enter the capacity you need at your conditions.
Model nomenclature
How to read the model codes of this series, with an example.
-
B
Number of fans — Digit 1-9.
-
C
Fan diameter — Two digits = diameter / 10 (91 = Ø910). 30 = Ø300 mm35 = Ø350 mm40 = Ø400 mm45 = Ø450 mm50 = Ø500 mm63 = Ø630 mm80 = Ø800 mm
-
E
Coil tube rows (2nd dimensional letter) C = 4 tube rowsD = 5 tube rowsE = 6 tube rowsG = 8 tube rows
-
F
Fin spacing 4 = 4.2-4.6 mm7 = 7.0 mm9 = 9.0 mm10 = 10.0 mm
-
G
Generation code — Catalogue: "Generation Code". A = generation A
-
H
Fan data (fan motor code) — Catalogue: "Fan Data". Two digits select the fan motor (supply, poles); the meaning is series-specific. 01 = fan motor code; supply/poles vary with diameter05 = single-phase 230 V 50 Hz, 4-pole AC fan (in this series)06 = three-phase 400 V 50 Hz, 6-pole AC fan (in this series)08 = three-phase 400 V 50 Hz, 4-pole AC fan (in this series)09 = single-phase 230 V 50 Hz, 4-pole AC fan (in this series)10 = three-phase 400 V 50 Hz, 4-pole AC fan (in this series)11 = three-phase 400 V 50 Hz, 4-pole AC fan (in this series)19 = three-phase 400 V 50 Hz, 4-pole AC fan (in this series)
EG-G (General)
- Capacity
- 0.77–9.48 kW
- Models
- 164
- Fans
- ⌀250, ⌀300, ⌀350 mm
- Max. pressure
- 10 bar
Downloads
Every model has a product datasheet (PDF) with its data, the standard ratings SC1–SC5 and the capacity table: open a model and choose Product datasheet.
Ask about product
Our engineers answer with a selection for your conditions.
The data are illustrative and may change without notice. Capacities are interpolated from the manufacturer's rating grid; points the manufacturer did not rate are shown as "not rated" and never estimated.
